GWS F-15 Strike Eagle



Wingspan 0.9m (35.4")
Wing Loading 36g/dm2 (11.8oz/sqft)
Flying Weight 864g (30.4oz)
Power Loading 350W/kg (159W/lb)
CG 165mm from bottom of fan intake ducts
Motor GWS BLM005A x2 (Green) 3050Kv
Ducted Fan GWS EDF64 x2
Speed Control HW Pentium 18A x2
Battery Thunder Power Prolite 2100-3S (11.1V)
Receiver Spektrum AR7000
Servos GWS Naro+FHPBB x2
Controls Tailerons, Motor
Construction Expanded Polystyrene Foam

F-15 3.jpg F-15 4.jpg fan.jpg F15_flight.jpg F-15_log.gif
